EASUN POWER Hybrid Solar Inverter 16.8KW 230vac MPPT 120A Solar Charger PV Input 6000W 450vdc LED Ring Lights Touchable Button 1 phase&3 phase

Original price $2,408.00 - Original price $2,408.00
Original price
$2,408.00
$2,408.00 - $2,408.00
Current price $2,408.00

Free shipping

Free returns

NO VAT

Secure payments

Ship From: Germany
Request a quote
Checkout Securely With
  • paypal
  • visa
  • master
  • maestro
  • jcb
  • american express
  • diners club
  • discover
  • unionpay

Authentic guarantee
12 months warranty
Fast return and exchange
Technical support

*IGrid SV IV 16.8KW = 3X IGrid SV IV 5.6KW +3X Parallel Kit

Main Features:

  • Customizable status LED ring with RGB lights
  • Touchable button with 4.3" colored LCD
  • Supports USB On-the-Go function
  • Data log events stored in the inverter
  • Self-consumption and Feed-in to the grid
  • Programmable supply priority for PV, Battery or Grid
  • User-adjustable charging current and voltage
  • Programmable multiple operationmodes:Grid-tie,off-gridand

grid-tie with backup

  • Built-in Wi-Fi for mobile monitoring (App is available)
  • Reserved communication port for BMS
  • Parallel operation up to 9 units

MODEL

IGridSV-IV-5.6KW

PHASE

1-phasein/1-phaseout

MAXIMUMPVINPUTPOWER

6000W

RATEDOUTPUTPOWER

5600W

MAXIMUMCHARGINGPOWER

6000W

GRID-TIEOPERATION

PVINPUT(DC)

NominalDCVoltage

MaximumDCVoltage

360VDC/450VDC

Start-upVoltage

InitialFeedingVoltage

110VDC/120VDC

MPPVoltageRange

120VDC~430VDC

NumberofMPPTrackers

MaximumInputCurrent

1/27A

GRIDOUTPUT(AC)

NominalOutputVoltage

220/230/240VAC

OutputVoltageRange

184-264.5VACor195.5-253VAC(Selectable)

NominalOutputCurrent

24.3A

PowerFactor

>0.9

EFFICIENCY

Maximum ConversionEffciency(DC/AC)

96%

OFF-GRIDOPERATION

ACINPUT

ACStart-upVoltage

AutoRestartVoltage

120-140VAC/180VAC

AcceptableInputVoltageRange

90-280VACor170-280VAC

MaximumACInputCurrent

40A

PVINPUT(DC)

MaximumDCVoltage

450VDC

MPPVoltageRange

120VDC~430VDC

NumberofMPPTrackers

MaximumInputCurrent

1/27A

BATTERYMODEOUTPUT(AC)

NominalOutputVoltage

220/230/240VAC

OutputWaveform

Puresinewave

Efficiency(DCtoAC)

93%

HYBRIDOPERATION

PVINPUT(DC)

NominalDCVoltage

MaximumDCVoltage

360VDC/450VDC

Start-upVoltage

InitialFeedingVoltage

110VDC/120VDC

MPPVoltageRange

120VDC~430VDC

NumberofMPPTrackers

MaximumInputCurrent

1/27A

GRIDOUTPUT(AC)

NominalOutputVoltage

220/230/240VAC

OutputVoltageRange

184-264.5VACor195.5-253VAC(Selectable)

NominalOutputCurrent

24.3A

ACINPUT

ACStart-upVoltage

AutoRestartVoltage

120-140VAC/180VAC

AcceptableInputVoltageRange

90-280VACor170-280VAC

MaximumACInputCurrent

40A

BATTERYMODEOUTPUT(AC)

NominalOutputVoltage

220/230/240VAC

Efficiency(DCtoAC)

93%

BATTERY&CHARGER

NominalDCVoltage

48VDC

MaximumSolarChargingCurrent

120A

MaximumACChargingCurrent

120A

MaximumChargingCurrent

120A

GENERAL

PHYSICAL

Dimension,DxWxH(mm)

140x295x468

NetWeight(kgs)

12

INTERACE

ParallelFunction

Yes,9units

CommunicationPort

USB/RS232/RS485/WIFI/Dry-contact

ENVIRONMENT

Humidity

0~90%RH(Non-condensing)

OperatingTemperature

-10to50ºC



SV-IV-5.6KW manual
