The Easun Power 6.2KP off-grid inverter with 120A MPPT solar charge controller is designed to be the ultimate energy solution for remote homes, cabins, RV's and more. With its pure sine wave output, built-in solar charge controller, and robust construction, it provides reliable and efficient power completely independent of the grid.
This inverter produces a pure sine wave output, which is vital for running sensitive electronics and appliances without any disruption or damage. The smooth and stable power allows you to run devices like computers, TVs, microwaves, etc seamlessly off-grid.
An integrated maximum power point tracking (MPPT) solar charge controller ensures you get the absolute most out of your solar panels. By tracking the optimal voltage and current, it can harvest 30% more power compared to PWM controllers. The high 120A rating supports large solar arrays up to 6500W.
The inverter equalization function brings faded batteries back to life by periodically applying an equalization voltage to eliminate sulfation and stratification. This restores each cell to an equal state of charge, optimizing battery performance and extending overall lifespan.
With its sturdy metal casing, sealed design and included anti-dust kit, it is specially built to survive harsh off-grid environments like deserts, mountains and marine applications. Advanced load management and cooling systems prevent overheating and overload failures.
The easy-to-use LCD display offers at-a-glance system metrics and settings customization. WiFi/GPRS connectivity sends data to mobile apps for instant remote monitoring and alerts. RS232/485 ports allow integration with external battery management systems.
Get the off-grid powerhouse designed for performance, efficiency and reliability with the Easun Power 6.2KP Inverter & 120A Solar Charge Controller. It's time to gain energy independence!
Have stock in EU now, we can shipping quickly and no need pay tax in European.
This is a multi-function inverter/charger, combining functions of inverter, MPPT solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.
Support connect lithium battery, communication with BMS port is RS232.
MODEL |
ISolar SMG II 6.2KP 48V WiFi |
Capacity |
6.2KVA/6.2KW |
Parallel Capability |
YES,12 Units |
INPUT |
|
Nominal Voltage |
230VAC |
Acceptable Voltage Range |
170-280VAC(For personal Computer);:90-280vac(For Home Appliances) |
Frequency |
50/60 Hz(Auto sensing) |
OUTPUT |
|
Nominal Voltage |
220/230VAC+5% |
Surge Power |
12400VA |
Frequency |
50/60Hz |
Waveform |
Pure Sine wave |
Peak Eficiency(PV to INV) |
96% |
Peak Efficiency(Battery to INV) |
93% |
Crest Factor |
3:1 |
BATTERY |
|
Battery Voltage |
48VDC |
Floatig Charge Volage |
54VDC |
OverCharge Protectin |
63VDC |
Charging Method |
CC/ CV |
Solar Charger & AC Charger |
|
Max.PV Array Power |
6500W |
Max.PV Array Open Circuit Voltage |
500VDC |
PV Array MPPT Voltage Range |
60VDC~450VDC |
Max.Solar Input Current |
27A |
Max.Solar Charge Current |
120A |
Max.AC Charge Current |
80A |
Max.Charge Current |
120A |
PHYSICAL |
|
Dimensions,D x W x H(mm) |
450*300*130 |
Package Dimensions,D x W x H(mm) |
540x390x210 |
Net Weight(Kg) |
12 |
Communication Interface |
RS232 / RS485 / Dry-contact |
ENVIRONMENT |
|
Operating Temperature Range |
(-10°C to 50°C) |
Storage Temperature |
(-15°C ~ 50°C) |
Humidity |
5% to 95% Relative Humidity ( Non-condensing ) |
Note: The inverter includes WiFi, which can be connected to mobile phone APP monitoring
Features:
*pure sine wave soalr inverter
*Output power factor 1
*High PV input voltage range
*Built-in MPPT soalr controller
*Battery equalization function to optimize
Battery performance and extend lifecycle
*Inverter running without barrery
*Built-in anti-dusk kit for harsh environment
*WIFI-GPRS remote monitoring (WIFI Plug included)
*Detachable LCD(Optional)
* Built-in Parallel Kit
